Pre stretch film pallet film rewinder is mainly includes the functions of pre stretching and rewinding, and it is mainly suitable for plastic film products such as PE stretch film,casting film, blowing film,pallet film,LLDPE film,LDPE film and cling film etc.
According to different stretch ratios, the length of the original film can be pre-stretched to 100-300% of the length. If the quality of the film is good, the pre-stretching ratio can be 400%, which effectively saves the cost of use.
Features:
1. Machine is easy and safe to operate, making the rewinding material smoother and stronger, and making the tension and puncture resistance better after contact with air.
2.Through rewinding, the staggered layer of the product can be corrected, and the flatness and appearance quality of the coil can be improved.
3.The diameter of the film roll paper core is from 1inch to 3 inches, which can be switched freely.
4.Machine is convenient and flexible to adjust, low noise, frequency conversion speed regulation,rewinding automatic counter, it is the ideal rewinding machine.
Main Data:
Name:Pre Stretch Film Pallet Film Rewinder
Model:PPD-SAPR500
Width of jumbo rol:500mm
OD of jumbo roll:max500mm
ID of jumbo roll:3inch
ID of product roll :2/3inch option
OD of product roll:max 300mm
Design speed:max 650rpm/min
Power:2.5kw
Voltage:220V/380V/415v 3ph option
NOTE:Different sizes can be customized.
