Automatic cling film cartoning machine integrates automatic box opening, material transfer, box folding, glue spraying, and box sealing.
Automatic cling film cartoning machine is controlled by PLC and human-machine interface,it adopts the principle of chain type moving continuously,the stability of the high-speed operation is ensured.
Automatic cling film cartoning machine is suitable for the industry of plastic wrap,aluminium foil roll,food paper roll,aluminium foil roll etc.
Features:
1.With the function of detecting lack of material in the box rack.
2..Automatic cling film cartoning machinebody is made of high-quality stainless steel, painted and combined with aluminum.
3.Automatic cling film cartoning machine has automatic waiting function and can work with rewinding machine together,the length of the machine is decided by customer’s paper box.
Main Data:
Name:Automatic Cling Film Cartoning Machine
Model:PPD-CM100
Max carton size:350*60*60mm(L*W*H)
Min carton size:150*30*30mm(L*W*H)
Available paper:≥350 G/SM
Noise:≤80db
Production speed:≤100 pc/min
Temperature:25± 10℃
Voltage:380V, 60Hz
Max power:4.0kw
Machine dimension:5050*2020*1750mm(L*W*H)
Machine weight:3000kg
