Stretch Film Slitter Rewinder

1000mm Narrow PE Stretch Film Slitting Rewinding Machine

1000mm Narrow PE Stretch Film Slitting Rewinding Machine

PPD-NSFS1000

1000mm narrow PE stretch film slitting rewinding machine is the updated model to slit and rewind of PE stretch film,Industrial stretch film,pallet stretch film,LLDPE film,HDPE film rolls in narrow rolls.

Features:

1.Different widths can be set,25/50/100mm option,max to jumbo roll.

2.Different size of sub-roll core diameter can be choose,like 1inch,2inch,3inch

3.3inch size adopt air shaft rewind,1.5 inch  and 2 inch adopt steel pipe rewind.

4.Easy take off the rewind roll than tranditional model.


Technical Data:

Name:Narrow PE Stretch Film Slitting Rewinding Machine

Model:PPD-NSFS1000

Jumbo roll width:max1000m

Jumbo roll OD:max500mm

Jumbo roll ID:3inch(76mm)

Sub roll width:25 to 1000mm

Sub roll ID: 1.5/2/3inch

Sub roll OD:max180mm

Speed:max 650m/min

Power:1.7kw

Voltage:220/380/415/450v

Air supply:0.2Mpa

11383408360_1709561269.jpg 微信图片_20211105161949.png
