2 shaft plastic film slitter rewinder is our latest design model for plastic film.
This model works with 2 exchange shaft to rewind,air shaft for rewinding roll slit and rewind,to ensure the final product flat and more easy to unload the product roll.
Features:
1.It is a kind of multi-functional machine integrated with slitting and rewinding, divide the large diameter film into several small rolls.
2. Slitting rewinding through 3 inch air shaft, the air shaft size can be customized sizes.
3. It is convenient and flexible to adjust, low noise, frequency conversion speed regulation, and automatic rewinding counter.
4.Suitable mateirals:PE stretch film,Industrial stretch film,Pallet stretch film,LLDPE film,HDPE film,OPP film,PVC/PE cling film etc
Main Data:
Name:2 Shaft Plastic Film Slitter Rewinder
Model:PPD-PFS500
Max width of parent roll:500 mm
Max diameter of parent roll:max400 mm
Inner diameter of parent roll:3inch
Production speed:600m/min
Width of sub-roll:50 mm-500 mm
Max diameter of sub-roll:max200 mm
Inner diameter of sub-roll:3inch air shaft or as customized sizes.
Paper core loading mode:By Manual
Cutting mode:By Knife
Voltage:220/440/415/380 V, 50/60 HZ, 3 phases.
Motor power:1.5 KW
NOTE：Different sizes can be customized.
