Automatic Stretch Film Rewinding Machine

Fully Automatic Extended Core Stretch Film Rewinder

Fully Automatic Extended Core Stretch Film Rewinder

PPD-ECRW500

Fully automatic extended core stretch film rewinder is specially designed for high speed rewind of PE ,LLDPE,HDPE stretch film roll into sub roll with extended core and standard core.
Machine is completed with PLC program by ergonomics,inverter controlled motor for speed,LCD touch screen for simple operation,self-diagnosis if any error appears.

Features:
1.The design speed is at 1200meter per minute for this model.
2.Machine wroks with auto converyor belt and receving table for collecting of product roll.
3.Machine is suit for rewinding of stretch film,pallet stretch wrap,industrial stretch wrapping film,food stretch wrap film,It is also designed for automatically PVC cling film rewinding.

Technical Data:

Name:Fully Automatic Extended Core Stretch Film Rewinder

Model:PPD-ECRW500

Width of film: 300-500mm option

Inner diameter of unwind roll:76mm

Sub roll width include extended core:400mm,500mm,520mm option

Inner diameter of sub roll:38mm/50mm/76mm

Outer diameter of rewind roll:max160mm

Speed:Max1200m/min

Voltage:220/380/415v,3ph

Power:4.37kw

NOTE:Different sizes can be customized.
