PE Food Wrap Paper Rewinder

Fully Automatic Silicon Paper Rewinding Machine

Fully Automatic Silicon Paper Rewinding Machine

PPD-SPR450

Fully automatic silicon paper rewinding machine is design for rewinding of food paper ,aluminium foil roll from jumbo roll to household rolls with the preset rewinding length.

Features:
1.Automatic feeding,less defect,safety,high efficiency and simple operating.
2.It can be done to feed pipe,rewinding,cutting certain foils in one process.
3.Automatic deliver the finished product through the conveyor belt,high efficiency.
4.Machine adopts PLC to be control system from Simens and uses computer control to set up and measure the length of silicon paper .baking paper or aluminium foil etc.

Main Data:

Name:Fully Automatic Silicon Paper Rewinding Machine

Model:PPD-SPR450

Thickness of Raw Material:0.009-0.025mm

Width of Raw Material:290-450mm

Maximum Unwinding Roll Diameter:600mm

Inner Diameter of Raw Material Roll Core:76mm or 152mm option

Inner Diameter of Finished Rewind Roll Core:25mm, 35mm, 38mm

Length of Rewinding Roll:Max150m

Production Speed:2-3m/second

Air Pressure:0.5Mpa

Magnetic Powder Brake:25N.M

Magnetic Powder Cluch:25N.M

Total Power:4.5Kw

Voltage:220/380/415V option

Packing size:3750*1700*2160mm

Weight:1700kgs

NOTE:Different sizes can be customized.
