Kraft paper slitter rewinder is used to slitting and rewinding of paper materials, such as 60gsm-300gsm base paper, kraft paper, paper-plastic composite materials and other roll materials.
Features:
1. Unwinding roll adopts shaftless hydraulic feeding structure, automatic brake tension structure control, high speed and convenience, and simple operation.
2. Machine adopts frequency conversion speed regulation to keep stable operation during acceleration;
3. The slitting device adopts a double-knife winding structure
4. The rewinding adopts the key-bar type air shaft structure, which is convenient for loading and unloading;
Technical Data:
Name: Kraft Paper Slitter Rewinder
Model:PPD-KPS1600
Slitting thickness: 60-300gsm
Diameter of raw material unwinding:max1300mm
Diameter of raw material rewinding: max1300mm
Width of rewinding material: 1600mm
Diameter of rewinding air shaft: 3 inches
Production speed: 50-240m/min
Voltage:380V,50hz
Power:22kw
