Automatic 4 turret aluminium foil roll rewinding machine PPD-4SHAR450 is newly developed model for non-stop production of 4 head turret automatic changing,it is adopted centering rewind method for very fine rewinding quality,it suits for aluminium consumer roll,aluminium house foil roll,kitchen foil roll,hairdressing roll etc.
With PLC HMI unit,the operation is very simple by touch screen only.
Fully auto convey belt will deliver the finished roll into packing area for operator to pack into the carton box.
The magnetic clutch system is durable for jumbo roll loading,the tension contorl system is automatic.
Main data:
Name:Automatic 4 turret aluminium foil roll rewinding machine
Model:PPD-4SHAR450
Material:aluminium foil
Master reel width:max 450mm
Master reel core dia:3/6inch
Master reel outer dia:600mm
Finished roll width:max 450mm
Finished roll core dia:32/35/38/40mm
Finished roll length:3-150meters
Speed:250m/min max
Power:3kw
Weight:800kg
Elcetricity:3phase
